Product video
Product details
Performance characteristics
1, Machine tool and beam are of good quality aluminum alloy which is anti-deformed, durable, economical and decent after the disposal of stress relieving and surface oxidation.
2. The combination of the T-bar and tailored track with dual drive acquires zero-noise, high-intensity, high-speed and high-precision features.
3, Equipped with two movable bodies which is convenient and practical.
4, Overvoltage protection function automatically eliminate the phenomenon of the torch at the bar when the arc voltage fluctuations caused by overrun .
5. Cutting Objects: carbon steel, stainless steel and non-ferrous metal plate.
6, With the function of cutting metal plates into any shapes.
7, With two cutting modes: Flame Cutting & Plasma Cutting.
8, Built-in power-on self-test diagnostic function,Can automatically memorize and restore when power is off.
9, LCD operation control box, the system can be easily set up, operate and monitor.
Product parameters
Model | DM3-4008 | DM3-5008 |
Gauge | 4000mm | 5000mm |
Cutting width | 3200mm | 4200mm |
Rail length | 8000mm | 8000mm |
Cutting length | 6000mm | 6000mm |
Maximum number of torches | 2 | 2 |
Cutting thickness(mm) | Flame 6-200mm, plasma 0.5-40mm | |
CNC system | Shanghai Jiaotong University / American Hypertherm | |
Drive mode | Bilateral step/bilateral servo drive | |
Working power | AC input 220v, 500-1000w | |
Cutting gas | Oxygen, Ethylene (propane, gas, natural gas or coke oven gas) | |
Plasma power | Domestic power supply / United States Haibao / United States Fei Matt / Germany Kiel Bay | |
Cutting speed | 10-6000mm/min | |
| Remark: The longitudinal track can be lengthened by 2m/section, and can be automatically adjusted (capacitance, arc voltage) | ||
