Product details
Performance characteristics
1. The body is a full steel plate welded structure, tempering aging, small deformation;
2. Using CNC (CNC) device, automatic processing;
3. Using air pressure device, clamping, release full automation;
4. The underside of the planer blade can be adjusted after wear to improve the service life of the whole machine;
5. Using five planers to work together, the efficiency of planing is high;
6. There is a detachable bracket in front of the table to facilitate the processing of long workpieces;
7. Full servo motor, accurate positioning, high precision;
8. All operating systems of the machine are precisely combined with electro-pneumatics, which is easy to operate, flexible in action, high in efficiency, low in noise, and free of environmental pollution.
Product parameters
| Model | Max.grooving width(mm) | Max.grooving length(mm) | Max.grooving thickness(mm) | Min.grooving thickness(mm) | Min.grooving distance(mm) | Cutting speed m/min(max) | Knife rest resolutiong(mm) | Positioning accuracy(mm) | Main motor power(kw) | Hydraulic system(Mpa) | Machine size(MM) |
| 1220X6000 | 1220 | 6000 | 6 | 0.5 | 8 | 65 | 0.001 | ±0.01 | 4.4 | 6-8 | 8200*2350*1900 |
| 1220X3200 | 1220 | 3200 | 6 | 0.5 | 8 | 65 | 0.001 | ±0.01 | 4.4 | 6-8 | 4700*2350*1950 |
| 1220X4000 | 1220 | 4000 | 6 | 0.5 | 8 | 65 | 0.001 | ±0.01 | 4.4 | 6-8 | 5500*2350*1950 |
| 1500X4000 | 1500 | 4000 | 6 | 0.5 | 8 | 65 | 0.001 | ±0.01 | 4.4 | 6-8 | 5500*2650*1950 |
| 1500X6000 | 1500 | 6000 | 6 | 0.5 | 8 | 65 | 0.001 | ±0.01 | 4.4 | 6-8 | 8200*2650*1980 |
