Product video
Product details
Performance characteristics
This machine is different from the traditional driving method mechanical shears. It is the most advanced small model shears. It enjoys good reputation both domestic and oversea. This machine with the electromagnetic disc brake equipment. The gear with the shaft is driven by the motor. The cutting angle is small. The cutting way is slant. So the cutting sheet without burr. And the cutting quality is good. This machine is a good chose for the metal sheet and the Non-metallic cutting.
Product parameters
Model | Cutting thickness | Cutting Width | Ram Stock | Back stop | Cutting angle | Working table height | Motor | Size |
MM | MM | MM-1 | MM | ° | MM | KW | MM | |
2.5X2500 | 2.5 | 2500 | 47 | 0-650 | 1 | 800 | 5.5 | 3214X2210X1180 |
3.2X2000 | 3.2 | 2000 | 47 | 0-650 | 1.45 | 800 | 7.5 | 2624X2210X1180 |
3.2X2500 | 3.2 | 2500 | 47 | 0-650 | 1.18 | 800 | 7.5 | 3214X2210X1180 |
2.5X1250 | 2.5 | 1250 | 47 | 0-650 | 1.30 | 800 | 5.5 | 1860X2210X1180 |
3.5X3050 | 3.5 | 3050 | 47 | 0-650 | 1.30 | 800 | 9 | 3599X2448X1290 |
Product video
Product details
Performance characteristics
This machine is different from the traditional driving method mechanical shears. It is the most advanced small model shears. It enjoys good reputation both domestic and oversea. This machine with the electromagnetic disc brake equipment. The gear with the shaft is driven by the motor. The cutting angle is small. The cutting way is slant. So the cutting sheet without burr. And the cutting quality is good. This machine is a good chose for the metal sheet and the Non-metallic cutting.
Product parameters
Model | Cutting thickness | Cutting Width | Ram Stock | Back stop | Cutting angle | Working table height | Motor | Size |
MM | MM | MM-1 | MM | ° | MM | KW | MM | |
2.5X2500 | 2.5 | 2500 | 47 | 0-650 | 1 | 800 | 5.5 | 3214X2210X1180 |
3.2X2000 | 3.2 | 2000 | 47 | 0-650 | 1.45 | 800 | 7.5 | 2624X2210X1180 |
3.2X2500 | 3.2 | 2500 | 47 | 0-650 | 1.18 | 800 | 7.5 | 3214X2210X1180 |
2.5X1250 | 2.5 | 1250 | 47 | 0-650 | 1.30 | 800 | 5.5 | 1860X2210X1180 |
3.5X3050 | 3.5 | 3050 | 47 | 0-650 | 1.30 | 800 | 9 | 3599X2448X1290 |
